Product Summary

The BSM150GB120DN2 is an IGBT Power Module.

Parametrics

BSM150GB120DN2 absolute maximum ratings: (1)Collector-emitter voltage: 1200V; (2)Collector-gate voltage: 1200V; (3)Gate-emitter voltage: ± 20V; (4)Power dissipation per IGBT: 1250W; (5)Chip temperature: 150℃; (6)Storage temperature: -40 to 125℃.

Features

BSM150GB120DN2 features: (1)Half-bridge; (2)ncluding fast free-wheeling diodes; (3)Package with insulated metal base plate.

Diagrams

BSM150GB120DN2 Circuit Diagram

Image Part No Mfg Description Data Sheet Download Pricing
(USD)		 Quantity
BSM150GB120DN2
BSM150GB120DN2
Infineon Technologies
IGBT Modules 1200V 150A DUAL
Data Sheet
0-1: $96.31
1-10: $86.68
