Product Summary
The 2MBI200U2A-060-50 is an IGBT module.
Parametrics
2MBI200U2A-060-50 absolute maximum ratings: (1)Collector-Emitter voltage: 600V; (2)Gate-Emitter voltage: ±20V; (3)Collector current-Continuous: 200A; (4)Collector current-1mS: 400A; (5)Collector Power Dissipation: 660W; (6)Junction temperature: 150℃; (7)Storage temperature: -40～+125℃; (8)Isolation voltage-between terminal and copper base: 2500VAC; (9)Screw Torque: 3.5N.m.
Diagrams
 |
