Product Summary
The CM150DY-24A is a low drive power IGBT. It is designed for use in switching applications. The CM150DY-24A consists of 2 IGBT transistors in a half-bridge configuration with each transistor having a reverse-connected super-fast recovery free-wheel diode. Applications include AC motor control, ups and battery powered supplies.
Parametrics
CM150DY-24A absolute maximum ratings: (1)junction temperature: -40 to 150; (2)storage temperature: 40 to 125; (3)collector emitter voltage: 1200V; (4)peak collector cuurent: 300A; (5)emitter current: 150A.
Features
CM150DY-24A features: (1)low drive power; (2)discrete super-fast recovery free-wheel diode; (3)isolated baseplate for easy heat sinking
Diagrams
| Image | Part No | Mfg | Description |  |
Pricing (USD) |
Quantity | ||||
|---|---|---|---|---|---|---|---|---|---|---|
 |
 CM150DY-24A |
|
IGBT MOD DUAL 1200V 150A A SER |
Data Sheet |
Negotiable |
|
||||
