Product Summary
The NL3224AC35-10 is a TFT (thin film transistor) active matrix color liquid crystal display (LCD) comprising amorphous silicon TFT attached to each signal electrode, a driving circuit and a backlight. The NL3224AC35-10 has a built-in backlight. The 14 cm diagonal display area contains 320 ×240 pixels and can display full-color (more than 16 million colors)simultaneously.
Parametrics
Absolute maximum ratings: (1)Supply voltage, VDC: –0.5 to 16.0 V at Ta = –20 to 65 ℃; VDCB: –0.5 to 16.0 V at Ta = –20 to 65 ℃; (2)Logic input voltage, VIN1: –0.5 to 5.5 V at Ta = –20 to 65 ℃; (3)Analog RGB input signal, VIN2: –2.5 to 2.5 V at VDC = 12 V; (4)Storage temp. ,TST: –20 to 65 ℃; (5)Operating temp., TOP: 0 to 65 ℃ at Module surface; (6)Humidity (no condensation): ≤ 90 % relative humidity at Ta ≤ 60 ℃.
Features
Features: (1)High luminance; (2)Analog RGB interface; (3)Reversible horizontal and vertical scanning; (4)Incorporated edge type backlight with Inverter; (5)Smooth polarizer surface.
Diagrams
<IMG border=0 src="http://www.seekic.com/uploadfile/ic-mfg/201212107478972.jpg">
 |
